Film Blowing Machine for Agriculture purpose

Product name：Film Blowing Machine for Agriculture purpose

Item：NRGPM-AG-SJ80;NRGPM-AG-SJ100;NRGPM-AG-SJ110

Details：

Model	NRGPM-AG-SJ80	NRGPM-AG-SJ100	NRGPM-AG-SJ110	NRGPM-AG-SJ120
Screw Diameter	80mm	100mm	110mm	120mm
Screw Ratio	L/D28:1	L/D28:1	L/D28:1	L/D28:1
Screw Speed	10-100r/min	10-100r/min	10-100r/min	10-100r/min
Output of Single-desk Extrude Machine	86kg/h	140kg/h	180kg/h	220kg/h
Power of Main Motor	30kw	55kw	75kw	90kw
Caliber of Film Head	Φ150-300mm	Φ500mm	Φ600mm	Φ750mm
Rotational Mode of Machine Head	Continuous rotate	Continuous rotate	Continuous rotate	连续旋转
Single-sided Thickness of Film	0.01-0.10mm	0.01-0.10mm	0.01-0.10mm	0.01-0.10mm
Max. Folding Width of Film	1500mm	2000mm	2500mm	3000mm
Total Power	56kw	88kw	110kw	145kw
Weight of Machine	6000kg	7600kg	9800kg	12000kg
Overall Dimensions	7000×2900×5500mm	8000×3500×8000mm	9000×4200×9600mm	10000×4600×11000mm
