Film Blowing & printing connect-line set

Product name：Film Blowing & printing connect-line set

Item：NRGPM-BP-SJ45;NRGPM-BP-SJ55;NRGPM-BP-SJ60

Details：

1) Models: a) NRGPM-BP-SJ45 b) NRGPM-BP-SJ55 c) NRGPM-BP-SJ60
2) Cylinders and screws of the extruder are made of high quality alloy steel with optimum hardness and strong corrosion resistance after nitrogen treatment and precision finishing.

3) Widely used for packing food, garments, and textiles .

OPTIONAL EQUIPMENT:
1. AUTO LOADER
2. CORONA
3. DIE ROTARY DEVICE
4. AIR COMPRESSOR
5. GRAVITY METRIC DEVICE

Model of machine	NRGPM-BP-SJ45	NRGPM-BP-SJ55	NRGPM-BP-SJ60
Stuitable material	LDPE、HDPE	LDPE、HDPE	LDPE、HDPE
Screw diameter	Φ45 mm	Φ55 mm	Φ60 mm
Screw L/D Ratio	L/D 28:1	L/D 28:1	L/D 28:1
Blowing film driving motor	11 kw	15 kw	18.5 kw
Max.Extrusion Output	35 kg/hr	50 kg/hr	70 kg/hr
Die size	40-80 mm	80-130 mm	100-160 mm
Width of blowing film	600 mm	800 mm	1000 mm
Thickness of blowing film	0.008-0.10 mm	0.008-0.10 mm	0.008-0.10 mm
Printing length	250-1000 mm	250-1000 mm	250-1000 mm
Precision of color printing	横向：0.2 纵向:0.2mm	横向：0.2 纵向:0.2mm	横向：0.2 纵向:0.2mm
Weight of overall	4300 kg	5000 kg	6200 kg
Cover dimensions(L×W×H)	7500×2000×3200mm	8000×2400×4000mm	8500×2600×4600mm
