Mini Film Blowing Machine with Double Color Printing Machine

Product name：Mini Film Blowing Machine with Double Color Printing Machine

Item：NRGPM-MP-SJ45;NRGPM-MP-SJ55

Details：

Mini type film blowing machine with double color printing machine, this machine is researched and developed successful by our company, it used for blowing and printing all kind of LDPE, HDPE and LLDPE, widely used for packing food, fruit, clothing, textile, garbage bags, vest bags and other civil and industrial packing.

Characteristics:
1.Film blowing and printing integrated machine
2.Double color: can print two color on one side or one color on each side
3.Easy operation
4.Small in occupied area
5.Save labor
6.Improve the output
7.Saving energy
8.Improve the quality of the products.

Model	NRGPM-MP-SJ45	NRGPM-MP-SJ55
Screw diameter	45mm	55mm
Screw ratio	L/D28:1	L/D28:1
Screw speed	10-100r/min	10-100r/min
Main power	7.5-11KW	11-15KW
Output of extruder	35kg/h	50kg/h
Max.width of film	600mm	800mm
Thickness of film (single-face)	0.006-0.10mm	0.006-0.10mm
Max.width of unwinding film for printing	550mm	750mm
Max.width of printing	400mm	600mm
Length of Printing range	191-600mm	191-800mm
Printing speed	5-50meter/min	5-50meter/min
Thickness of rubber plate with double-face adhesive tape	2.38mm	2.38mm
Total power	22kw	25KW
Weight of machine	1900kg	2100kg
Dimension of machine	2300x1500x2550mm	2710x1500x2650mm
