Middle Speed Paper Bowl Forming Machine

Product name：Middle Speed Paper Bowl Forming Machine

Item：NRGPF-PB-SP150

Details：

This machine is as based on normal speed paper cup forming machine.Then researched and developed,the intensity and stability of it have been improved greatly. It produced of silicon oil lubrication,bottom punching heating,kunrling,curling and cup discharge,This kind of cup be beverage,ice cream etc.This machine has adopted new technology,imported hot blowing equipment and high speed accurate cam indexing unit.It has good feature of precise equipment,and it is the first choice for the paper cup manufacturer.

Technical Parameters

Model	NRGPF-PB-SP150
Bowl size	60-150 ounce,KFC out-take barrel and etc.
Output	30-35pcs/mim
Main Moto power	2.2kw
Electric heating power	8kw
Total power	15kw
Air source	0.4m³/min;0.5MPa
Raw material	350-420g/㎡（single or double PE coated paper）
Weight	4500kg
Dimension	3300×2000×2200mm 940×600×1900mm
