Single-faced and Double-faced PE Laminating Cup Handle Integral

Product name：Single-faced and Double-faced PE Laminating Cup Handle Integral

Item：NRGPF-SF-SP12

Details：

NRGPF-SF-SP12 single-faced and double-faced PE laminating cup handle integral forming machine is a multiple-stage full-automatic machine. Through continuous processes such as cup wall paper and cup handle paper feeding, ultrasonic wave welding, adhesion of the wall paper and the handle paper, cup mouth lubrication, bottom punching, bottom heating, knurling, upper mouth hemming and finished product piling, the machine produces single-faced and double-faced PE coated hot drink cups with handle or conical vessels of other foods. Due to the adoption of cup-handle integrated technology, the machine not only can produce paper cup with handle, but also can produce paper cup without handle, and is suitable for producing conical vessels such as single-faced and double-faced PE coated full printing hot drink cups.

Technical Parameters

Machine Type	NRGPF-SF-SP12
Paper Cup Specification	6 ounces 8 ounces 12 ounces
Cup Paper Material	double-faced PE coated paper
Cup Height	50-120mm
Rated Productivity	40-50 pieces/minute (pcs/min)
Power	380V 50Hz(it can be changed if customer require)
Total Power	6.5KW
Weight	1,800Kg
Packing Measurements (LWH)	3,2001,3501,800mm 8007501,300mm
Power Supply Requirements	0.2m3min;0.6MPa (chosen by the customer)
