Rotary Head Film Blowing Machine

Product name：Rotary Head Film Blowing Machine

Item：NRGPM-RH-SJ55;NRGPM-RH-SJ60;NRGPM-RH-SJ65

Details：

NRGPM-RH-SJ55 Rotary Head Film Blowing Machine Set

The cylinders and the screw stems of the extruder are made of high quality alloy steel with optimum hardness and strong corrosion resistance after nitrogen treatment and precision finishing. The auxiliary machine has a plat from working table for making operation easy and is equipped with bubble stab ilizing ring.Double-rolling and double-cutting coiling unit adopts torque motor to motor to keep proper tension and make even and roll-changing easy.

OPTIONAL EQUIPMENT:
1. AUTO LOADER
2. CORONA
3. DIE ROTARY DEVICE
4. AIR COMPRESSOR
5. GRAVITY METRIC DEVICE

Model	NRGPM-RH-SJ55	NRGPM-RH-SJ60	NRGPM-RH-SJ65	NRGPM-RH-SJ80	NRGPM-RH-SJ100
Screw Diameter	55mm	60mm	65mm	80mm	100mm
Screw Ratio	L/D28:1	L/D28:1	L/D28:1	L/D28:1	L/D28:1
Screw Speed	10-100r/min	10-100r/min	10-100r/min	10-100r/min	10-100r/min
Main Output	50kg/h	65kg/h	70kg/h	86kg/h	140kg/h
Power of Main Motor	15kw	18.5kw	22kw	30kw	55kw
Specification of Die Head	Φ100-150mm	Φ100-180mm	Φ120-220mm	Φ150-300mm	Φ500mm
Rotational Mode of Machine Head	Continuous rotate	Continuous rotate	Continuous rotate	Continuous rotate	Continuous rotate
Single-sided Thickness of Film	0.01-0.10mm	0.01-0.10mm	0.01-0.10mm	0.01-0.10mm	0.01-0.10mm
Max. Folding Width of Film	800mm	1000mm	1200mm	1500mm	2000mm
Total Power	26kw	30kw	42kw	56kw	88kw
Weight of Machine	2300kg	3000kg	3800kg	4600kg	6000kg
Overall Dimensions (L×W×H)	6000×2000× 4000mm	6500×2200× 4500mm	6800×2400× 4800mm	7000×2700× 5500mm	8000×3200× 7600mm
